MCD-MissionLINK Global WiFi Satellite Internet Hotspot

Name: MCD-MissionLINK Global WiFi Satellite Internet Hotspot
Brand: Brand
SKU: MCD-MissionLINK
Price: 20497.48 AUD
Availability: InStock

One-Button WiFi Hotspot Case - 100% Global
Place the MCD-MissionLINK case ANYWHERE under an open sky and press the power button and close the case lid... In a minute the terminal will become a waterproof WiFi hotspot up to 300 meters (1,000 feet) from the case for high-speed Internet and phone anywhere on the globe, including the north and south poles. The MCD-MissionLINK is an easy to use 100% global office.

THALES MISSIONLINK BROCHURE (PDF)

SEE ALL DOWNLOADS

A$20,497.48

MODEL:

MCD-MISSIONLINK

PART #:

MCDML350

WARRANTY:

24 MONTHS

Stock Status:

In stock

AVAILABILITY:

USUALLY SHIPS IN 2-3 BUSINESS DAYS

Product Code:

MCD-MissionLINK

MCD-MissionLink Global WiFi Hotspot

Portable Internet & Phone
The MCD-MissionLINK requires no user training to operate. Like all of our MCD products, simply place the "closed" weather-tight sealed case on the ground or on a moving vehicle/platform under an open sky, rain or shine and turn it on - no pointing necessary. The terminal connects with the Iridium Certus satellite network and broadcasts a WiFi hotspot (up to 300 meters - 1,000 feet) for up to 12 devices... and runs for about 5 hours on internal battery. This carry-portable case uses the new Thales MissionLINK satellite terminal integrated with our proprietary mobile electronics for a ruggedized self-contained, in-field, user-friendly worldwide communications solution.

More Information
PRODUCT TYPE	SATELLITE INTERNET
USE TYPE	MARITIME, PORTABLE
MODEL	MCD-MISSIONLINK
PART #	MCDML350
NETWORK	IRIDIUM
CONSTELLATION	66 SATELLITES
USAGE AREA	100% GLOBAL
SERVICE	IRIDIUM CERTUS LAND
MAXIMUM DOWNLOAD SPEED	UP TO 700 Kbps
MAXIMUM UPLOAD SPEED	UP TO 352 Kbps
LENGTH	525 mm
WIDTH	437 mm
DEPTH	213 mm
WEIGHT	16.5 kg
FREQUENCY	L BAND (1-2 GHz)
INGRESS PROTECTION	IP 66
TALK TIME	UP TO 5.5 HOURS

MCD-MissionLINK Features
- No pointing or aiming... Simply turn the unit on under an open sky.
- Connects automatically with Iridium Certus network for 100% global service.
- 100% Global connectivity on land or sea under the same service plan.
- Internet speeds of up to 700 Kbps - Now available!
- Does not require user interaction. No software to run. Establishes AP "Hotspot" automatically.
- Ruggedized. Operates in extreme conditions. Case does not need to be opened to operate.
- Operates stationary, or in-motion such as on top of a vehicle for other moving platform.
- 1,000' (300 meter) wireless range WiFi hotspot for laptops, smartphones...any wireless device.
- Connect up to 12 wireless devices. WiFi WPA2 Security & MAC address whitelisting.
- External all weather Ethernet (RJ-45) and Phone (RJ-11) connection ports.
- External ports allow for hard-wired waterproof Ethernet and phone connections to any device.
- Up to 5-6 hour battery life (rechargeable) for normal use.
- May be plugged into a vehicle 12V power port for continuous operation or charging.
- Includes standard analog phone. The RJ-14 jack has two separate phone lines.
- No rain fade - Operates in heavy rain.
- Internal temperature control fan - cools internal electronics during high temperatures.
- Watertight, crushproof, dust proof reinforced plastic case.
- Backlight 24x7 battery display shows power remaining. Can be enabled/disabled.
- Portable - Ships UPS, FedEx, flight carry-on luggage anywhere.
- Internal battery is not Lithium-Ion, so no flight restrictions. Carry portable.
- Full IP compatibility - Internet, SMTP email, file transfer, IP protocols.
- Global public / static IP addresses are available from Ground Control.
- Remote access to connected devices with Public IPs & firewall controls-
- Internet domain whitelists and blacklists configurable from terminal.
- Location tracking services - Send coordinates to any server with any time frequency.
- Custom engineering available... such as adding special equipment inside a larger case.
- 2 Year standard warranty. 3 year and 5 year warranties available.

MCD-MissionLINK Contents
- MCD-MissionLINK Flyaway Portable Case
- AC/DC power supply (110/240 VAC)
- Standard analog phone
- Mini DC inverter for running off vehicle power
- AC plugs for U.S., U.K., EU, AU, China, N. Europe
- Ethernet cable - 10' feet / 3 meters
- Compass.
- USB flash drive with user manuals or here
- Carry bag to hold accessories

Iridium Global Coverage Map

Iridium delivers essential communications services to and from remote areas where no other form of communication is available. Powered by a uniquely sophisticated global constellation of 66 cross-linked Low-Earth Orbit (LEO) satellites, the Iridium® network provides high-quality voice and data connections over the planet’s entire surface, including across airways, oceans, and polar regions. Together with its ecosystem of partner companies, Iridium delivers an innovative and rich portfolio of reliable solutions for markets that require truly global communications.

At only 780 kilometers from the Earth, the proximity of Iridium’s LEO network means pole-to-pole coverage, a shorter transmission path, stronger signals, lower latency, and shorter registration time than with GEO satellites. In space, each Iridium satellite is linked to up to four others creating a dynamic network that routes traffic among satellites to ensure global coverage, even where traditional local systems are unavailable.
