Intellian OneWeb Maritime Dual Parabolic User Terminal (OS-OW50M)

A$41,735.00 A$36,324.91
BRAND:
INTELLIAN
MODEL:
MARINE USER TERMINAL
PART #:
OS-OW50P / OW50M
ORIGIN:
South Korea
Stock Status:
In stock
AVAILABILITY:
ALLOW 2-4 WEEKS FOR DELIVERY
Product Code:
OneWeb-User-Terminal-Maritime

Intellian OneWeb Dual Parabolic User Terminal for Maritime (OW50M)
The OW50M is a maritime-based user terminal for OneWeb's Low Earth Orbit (LEO) satellite constellation. It consists of dual 3 axis stabilized pedestals with 73 cm parabolic antennas providing 12 dB/K G/T performance. By allowing seamless and undisrupted connectivity for LEO handovers, this user terminal gives customers in remote and challenging environments access to a cost effective and enhanced user experience otherwise inaccessible to them.

Low Latency, Fast Speed
Providing global coverage (including both poles) OneWeb’s 648 satellite constellation will provide fibre-like high speed, low latency connectivity to remote customers where terrestrial fibre connections are not possible. The OW70L-Dac operates in Ku-Band for minimum rain fade and is able to deliver unmatchable high-throughput, low-latency connectivity.

High-performance
The OW50M is a cutting-edge user terminal that brings highspeed, low latency communications to maritime customers. With its 53cm reflector and data speeds of up to 195 Mbps downlink and 16 Mbps uplink, the OW50M enables high-speed applications for passenger and crew welfare while facilitating real-time critical operational communications. Users will also benefit from access to OneWeb’s guaranteed CIR throughputs, ensuring consistent and reliable performance while at sea.

Low Temperature Performance
Utilizing the latest heating device technology, the OW50M provides dependable performance in extremely low temperatures (-40 degrees Celsius). With Eutelsat OneWeb being the only LEO constellation committing to 100% coverage of the poles, you can be assured of optimal connectivity for vessels travelling in both polar regions.

Easily Deployable System
Designed with cost-effectiveness in mind, the OW50M comes pre-assembled and designed for easy installation. With only a single cable needed to provide data and power between above and below deck units, installation time and complexity is significantly reduced.

LEO satellite scan and tracking algorithm
The Intellian OW50M provides seamless, undisrupted connectivity through a primary-primary dual dome solution for consistent connection with LEO satellite handovers. Each antenna operates independently offering enhanced flexibility to mitigate blockages and ensure optimal integrity of high-speed data transfer and low latency.

9.3 dB/K antennas with 3 axis stabilization
- 3 axis stabilization allows seamless tracking of LEO satellites even when the ship is in motion

- Full frequency operation on the OneWeb constellations providing a 10.7 – 12.7 GHz Forward link and a 14.0 – 14.5 GHz Return link

More Information
HARMONIZED TARIFF NUMBER85176200
PRODUCT TYPESATELLITE INTERNET
USE TYPEMARITIME
BRANDINTELLIAN
MODELMARINE USER TERMINAL
PART #OS-OW50P / OW50M
NETWORKONEWEB
CONSTELLATION648 SATELLITES
FEATURESINTERNET
DIAMETER53 cm (20.9 inches)
WEIGHT52 kg | 54 kg with heating module
FREQUENCYKu BAND
RECEPTION FREQUENCYKu-band: 10.7 ~ 12.75 GHz
BROCHURES
pdf
 (Size: 461.2 KB)
